TECHNICAL SPECIFICATION

Measuring Data

Throughput - 60 tests/hour

34Parameters – WBC, LYM%, MON%, NEU%, EOS%, BASO%, LYM#, MON#, NEU#, EOS#, BAS#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW_CV, RDW_SD, PLT, MPV, PDW, PCT, P _LCR, P_LCC, NRBC%, NRBC RETIC%_ABS, RETIC#, IRF, ALY%, ALY#, LIC%, LIC#

2 Histograms for RBC and PLT

2 Scatter grams: 5-part differential scatter gram

Eosinophils and Neutrophils scatter gram

2 3-D stereograms

Principle of Operations

WBC/DIFF: Flow Cytometry, Semi-conductor. Based Laser light multi-dimensional cell classification

WBC Analysis: Optical and impedance measurements

RBC/PLT Analysis: Impedance method

HGB test: Cyanide-free reagent colorimetry

Calibration and Control

With standard, blood and manual calibration

With L-J, X, X-R and X-B control modes.

Technical Features

Multiuser mode- Multilevel user modes with individual identification (username, password)

Data storage capacity - 200,000 records with graphics

Printout - Internal Thermal Printer, External most of the HP printers

External keyboard - PS/2 or USB

Interfacing capabilities - RS232, USB, Ethernet

Software upgrade - via USB port (USB memory stick)

Operating environment - Temperature: 15–30°C

Relative humidity - max 80% (non-condensing)

User Interface

Display: 10.4 inch with touch screen

Reagents and Sampling System Samples

Diluent, Sheath, Detergent,Lyse

Whole blood : 20µL

Pre-diluent : 20µL

Dimensions

Size (Width x Depth x Height): 46 cm x 49 cm x 33 cm

Weight: 35 kg

• Easy to use, affordable and best in class technology with 60 samples/hour throughput
• Large touch screen display with in-built thermal printer facility
• 34 parameters including RET%, RET# and other research parameters
• Double WBC counting mode for accurate and reliable differential count
• Laser light multi-dimensional classification with resistant RBC Mode
